Acrel APM Series User Manual

18
Table 1: Extreme Values and symbol description
Symbol
Instruction
Symbol
Instruction
Symbol
Instruction
IA
Phase A current
PT
Total active power
IHC
Total harmonic of
Phase C current
IB
Phase B current
QA
Phase A reactive power
UHA
Total harmonic of
Phase A voltage
IC
Phase C current
QB
Phase B reactive power
UHB
Total harmonic of
Phase B voltage
IN
Neutral current
QC
Phase C reactive power
UHC
Total harmonic of
Phase C voltage
IAV
Average current
QT
Total reactive power
UA
Phase A voltage
SA
Phase A apparent power
UB
Phase B voltage
SB
Phase B apparent power
UC
Phase C voltage
SC
Phase C apparent power
ULN（AVG）
Average phase
voltage
ST
Total apparent power
UAB
Phase AB line
voltage
PFA
Phase A power factor
UBC
Phase BC line
voltage
PFB
Phase B power factor
UCA
Phase CA line
voltage
PFC
Phase C power factor
ULL（AVG）
Average line
voltage
PFT
Total power factor
PA
Phase A active
power
F
Frequency
PB
Phase B active
power
IHA
Total harmonic of Phase
A current
PC
Phase C active
power
IHB
Total harmonic of Phase
B current
