17
View maximum and minimum values: Press
◀▶
key on the main screen until the current measurement data display area shows MAX
MIN and press enter. Press ◀▶ key to select the extreme value record of the electric parameters (I, U, P, Q, S, PF, F, THD, etc.) to be
viewed and press the Enter key. Press the
◀▶
key to view the current month's maximum value, the current month's minimum value, the
previous month's maximum value, the previous month's minimum value, and the time of occurrence of the selected electrical
parameter. When a month span occurs, the extreme value of this month is automatically deposited into the extreme value of the
previous month.
Maximum and minimum
Select extreme value (Phase A current is selected currently)
The current month's maximum value
The current month's minimum value
The previous month's maximum value
The previous month's minimum value
Others refer to table 1
The time of occurrence of phase A
current is 16-9-8 3:58
