Acrel APM Series User Manual

21
4 UA
Over THD of phase A voltage
44
5 UB
Over THD of phase B voltage
45
6 UC
Over THD of phase C voltage
46
AT10 (Total Even
Harmonic Alarm)
EVEN
1 IA
Over TEHD of Phase A current
47
2 IB
Over TEHD of Phase B current
48
3 IC
Over TEHD of Phase C current
49
4 UA
Over TEHD of Phase A voltage
50
5 UB
Over TEHD of Phase B voltage
51
6 UC
Over TEHD of Phase C voltage
52
AT11 (Total odd
harmonics Alarm)
Odd
1 IA
Over TOHD of Phase A current
53
2 IB
Over TOHD of Phase B current
54
3 IC
Over TOHD of Phase C current
55
4 UA
Over TOHD of Phase A voltage
56
5 UB
Over TOHD of Phase B voltage
57
6 UC
Over TOHD of Phase C voltage
58
AT12
di
1 di1
DI1 ON/OFF
62
2 di2
DI2 ON/OFF
63
3 di3
DI3 ON/OFF
64
4 di4
DI4 ON/OFF
65
AT13
（
Other
）
Oth
1 I-Ubl
Max unbalanced current
10
2 U-Ubl
L-N
Max unbalanced phase voltage
28
3 U-Ubl
L-L
Max unbalanced line voltage
29
4 F Over
Over Frequency
39
5 F Unde
Under Frequency
40
6 I Loss
Current Loss
11
7 U Loss
Voltage Loss
30
8 PHA Rev
Phase Reversal
61
AT14(Temperatur
e)
Temp
1
1
st
way temperature
66
2
2
nd
way temperature
67
3
3
rd
way temperature
68
4
4
th
way temperature
69
To check the temperature and humidity:Press < ▶ >key in the main interface,Until the current measurement data
display area displays TE, the measurement data area displays temperature,then press< ENTER>key.You can check
the four channel temperature.At the temperature interface press < ▶ > Key to check the temperature and humidity
sensor value and the state of the heating blast.
