Acrel APM Series User Manual

24
IC(A)
Phase C current
U_LL_AVG(V
)
Average line
voltage
QB(Var)
Phase B reactive
power
IN(A)
Neutral current
UA_UBL(%)
Unbalance of Phase
A voltage
QC(Var)
Phase C reactive
power
I_AVG(A)
Average
current
UB_UBL(%)
Unbalance of Phase
B voltage
QT(Var)
Total reactive
power
IA_UBL(%)
Unbalance of
Phase A current
UC_UBL(%)
Unbalance of Phase
C voltage
SA(VA)
Phase A apparent
power
IB_UBL(%)
Unbalance of
Phase B current
U_LN_UBL(
%)
Unbalance of phase
voltage
SB(VA)
Phase B apparent
power
IC_UBL(%)
Unbalance of
Phase C current
UAB_UBL(%
)
Unbalance of AB
line voltage
SC(VA)
Phase C apparent
power
I_UBL(%)
Unbalance of
current
UBC_UBL(%)
Unbalance of BC
line voltage
ST(VA)
Total apparent
power
UA(V)
Phase A
voltage
UCA_UBL(%
)
Unbalance of CA
line voltage
F(Hz)
Frequency
UB(V)
Phase B
voltage
U_LL_UBL(
%)
Unbalance of line
voltage
PFA
Phase A power
factor
UC(V)
Phase C
voltage
PA(W)
Phase A active
power
PFB
Phase B power
factor
U_LN_AVG(
V)
Average phase
voltage
PB(W)
Phase B active
power
PFC
Phase C power
factor
UAB(V)
AB line voltage
PC(W)
Phase C active
power
PF
Total power factor
⑥
View event log data: Open the SOE folder, which contains the .csv log file named "Year_Month" (for example: 2018_03.csv) to
view the event log data. The log file contains: date; time; DIDO serial number; action type.
⑦
Check the Temperature and humidity data: open the Temperature folder, folder containing "year _ month _ date" named. CSV record
file (such as :2020_03_31. CSV), you can see the Temperature and humidity data.The record file contains: date;Time;Temperature and
humidity measurement;Maximum and minimum.
Note: The data in the TF card is read-only, and the file record data is excel. Please open it with Microsoft Office Excel07
version and above 07 version. If it is lower than Microsoft Office Excel07 version or WPS, there will be some data loss.
