Acrel APM Series User Manual

23
APM800Config.ini (Parameter log file settings), Temperature
（
Temp&Humidity data
）
ReadMe.txt (Guide).
Note: If the system time is set incorrectly, the TF card will not be recognized.
①
Alarm data: Open the Alarm folder. The folder contains subfolders named
“
Year_Month
”
(For example: 2018_02). The subfolder
contains the .csv record file named “Alarm Type” (eg: Over THD. Csv), you can view the alarm data. The log file contains: date;
time; alarm group; alarm type; alarm value; alarm status.
②View the timed energy record data: Open the Energy folder, and the folder contains the .csv record file (2018_02.csv) named
“
Year_Month
”
to view the timed energy record data. The log file contains: date; time; positive active energy; reverse active energy;
inductive reactive energy; capacitive reactive energy; positive active energy in T1 period; positive active energy in T2 period; positive
active energy in T3 period; positive active energy in T4 period.
Note: The meter records 1 time energy data (primary side) by default for 1 hour. It also includes the positive active energy in
each time period. The time interval can be set. The time interval unit is Hour.
Symbol
Content
Symbol
Content
IMP
Positive active energy
IMP(T1)
Positive active energy in T1 period
EXP
Reverse active energy
IMP(T2)
Positive active energy in T2 period
EQL
Inductive reactive energy
IMP(T3)
Positive active energy in T3 period
EQC
Capacitive reactive energy
IMP(T4)
Positive active energy in T4 period
③View harmonic data: Open the Harmonic folder, which contains subfolders named "Year_Month" (For example: 2018_03), and the
subfolder contains a .csv log file named "Year_Month_Date" (eg :2018_03_31.csv), you can view harmonic data. The log file contains:
date; time; three-phase phase-separated voltage, current total harmonic value (maximum, minimum); three-phase phase-separated
voltage, total odd current harmonic, total even harmonic value (maximum, minimum) ); three-phase phase-separated voltage and
current fractional harmonic values (maximum, minimum, recorded 2-63 harmonic data).
Note: The meter records 1 time harmonic data (primary side) by default for 1 minute, the time interval can be set, and the time
interval unit is minute.
④
View the main parameter change record: Open the Maintain folder, the folder contains the "Maintain.csv" log file, you can view the
parameter change record. The log file contains: date; time; parameter type (such as: primary side voltage and current value; secondary
side voltage and current value; 485 communication address and baud rate); new parameter value.
⑤ View timed electrical parameter record data: Open the Record folder, which contains subfolders named “ Year_Month ” (eg
2018_03), and the subfolder contains the .csv log file named
“
Year_Month_Date
”
(Example: 2018_03_31.csv), you can view the
timed electrical parameter record data. The log file is as follows:
Note: The meter records 1 time electric parameter data (primary side) by default for 1 minute, the time interval can be set, and
the time interval unit is minute.
Symbol
Content
Symbol
Content
Symbol
Content
IA(A)
Phase A current
UBC(V)
Phase BC line
voltage
PT(W)
Total active power
IB(A)
Phase B current
UCA(V)
Phase CA line
voltage
QA(Var)
Phase A reactive
power
