Acrel APM Series User Manual

38
7.5.15 Recording configuration of TF card
1. Insert the TF card into the computer, find the corresponding drive letter and open it.
2. Double-click to open APM800Config.ini.
3. [INTERVAL] is a configuration area of sampling interval.
Parameter (minute), indicates the recording interval of electrical parameter in minutes and range (1-30).
Energy (hour), indicates the recording interval of energy in hours and range (1-12).
[PARAMETER] is the configuration area to record the electrical parameter. For example: IA=1 means to record Phase A current,
IA=0 means not to record Phase A current.
[ENERGY] is the configuration area to record energy configuration. For example: IMP = 1 means to record absorbed active
energy, and IMP = 0 means not to record absorbed active energy.
4. Save after configuration is complete.
