Acrel APM Series User Manual

50
1.Register listing
Register
Description
unit
Data Type
Parameters
0
Meter address(COMM1)
Int16 (RW)
Range :1-247
1
Baud rate(COMM1)
Int16 (RW)
0：38400
1：19200
2：9600(default)
3：4800
4：2400
5：1200
2
Parity(COMM1)
Int16 (RW)
0：None Parity with one stop bit(default)
1：None Parity with two stop bits
2：Odd Parity with one stop bit
3：Even Parity with one stop bit
3
System Type
Int16 (RW)
Lower 7 bit
：
0:3P3W_2CT,
1:3P4W,
2:3P3W_3CT
4
Nominal Secondary Current
Int16 (RW)
1A or 5A
5
Nominal Secondary Voltage L-L
Int16 (RW)
100V
、
110V
、
400V
、
690V
6
Nominal Primary Current
1A
Int16 (RW)
0-32760A
7-8
Nominal Primary Voltage L-L
1V
Int32 (RW)
0-1200KV
Meter address(COMM2)
10
Baud rate(COMM2,slave)
Int16 (RW)
0
：
38400
1
：
19200
2
：
9600
3
：
4800
4
：
2400
5
：
1200
11
Parity(COMM2,slave)
Int16 (RW)
0
：
None Parity with one stop bit
1
：
None Parity with two stop bits
2
：
Odd Parity with one stop bit
3
：
Even Parity with one stop bit
13
Neutral current secondary side rating
Int16 (RW)
1A or 5A
14
Neutral current primary side rating
1A
Int16 (RW)
1A-32760A
15
Pulse constant
100
Int16 (RW)
0-9999(APM801 is valid) (When it is 0,
default value is used, 1A: 8000, 5A: 4000;
When it is not 0, pulse constant = register
value *100)
16
Unbalance algorithm
Int16 (RW)
Unbalance algorithm(0: Rated, 1: Absolute)
18
Profibus address
Int16 (RW)
1-127
20
Year
Int16 (RW)
0-99
21
Month
Int16 (RW)
1-12
22
Day
Int16 (RW)
1-31
23
Hour
Int16 (RW)
0-23
24
Minute
Int16 (RW)
0-59
