Acrel APM Series User Manual

51
25
Second
Int16 (RW)
0-59
29
Enable change parameter of Ethernet
from RS485 Port
Int16 (RW)
code: 0XABCD
30-31
IP Address
Int32 (RW)
Sample
：
192.168.3.8
ADDR 30:C0A8H
ADDR 31: 0308H
32-33
Subnet Mask
Int32 (RW)
Sample
：
255.255.255.0
ADDR 32
：
FFFFH
；
ADDR 33
：
FF00H
34-35
Gateway
Int32 (RW)
Sample：192.168.3.1
ADDR 34：C0A8H；
ADDR 35：0301H
36
Port Number
Int16 (RW)
0-9999
37
IP address allocation
Int16 (RW)
0: Manual; 1: Automatic (DHCP)
38
The code for Save the parameter of
Ethernet
Int16 (RW)
code: 0XABCD
40
SD Storage State
Int16 (RO)
0,0x11
：
No SD Card
0x22
：
Bad SD Card
0x33
：
SD work well
0x44
：
Full storage
0x55
：
Formating
0x66
：
Error in Configuration File
41
SD Total capacity
1M
Int16 (RO)
Unit : Megabytes
42
SD Residual capacity
1M
Int16 (RO)
Unit : Megabytes
61
Nominal voltage
0.1V
Int16 (RO)
Secondary side nominal voltage for
calculating voltage deviation
120
Blast cooling value (Module 1)
0.1℃
Int16 (RW)
0-9999
121
Blast cooling hysteresis
0.1℃
Int16 (RW)
0-9999
122
Blast cooling delay
1s
Int16 (RW)
0-9999
123
Heating up value
0.1℃
Int16 (RW)
0-9999
124
Heating up hysteresis
0.1℃
Int16 (RW)
0-9999
125
Heating up delay
1s
Int16 (RW)
0-9999
126
Heat dehumidification value
0.1%
Int16 (RW)
0-9999
127
Heat dehumidification hysteresis
0.1%
Int16 (RW)
0-9999
128
Hysteresis delay
1s
Int16 (RW)
0-9999
62
Nominal frequency
0.01Hz
Int16 (RO)
Nominal frequency used to calculate
frequency deviation
242
Neutral current,
0.001A
Int16 (RO)
Secondary
243
Voltage A-N
0.1
Int16 (RO)
Secondary
244
Voltage B-N
0.1
Int16 (RO)
Secondary
245
Voltage C-N
0.1
Int16 (RO)
Secondary
246
Voltage A-B
0.1
Int16 (RO)
Secondary
247
Voltage B-C
0.1
Int16 (RO)
Secondary
