17
indicates that the current protocol is not enough to display, the actual data read by
the identifier 02020100 is divided by 1000;bit2 indicates that the power protocol
is not enough to display, and the 02030000 identifier actually reads data divided
by 1000;
04808083
2
实际电流倍数，额定电流
1.2
倍
999A
以内为
1
，超过
999A
为
1000
（
02020100
读取值被除以 1000）
Actual current ratio, 1.2 times rated current within 999A is 1, over 999A is 1000
(02020100 reading value is divided by 1000)
04808084
2
实际功率倍数，额定功率
1.2
倍
99KW
以内为
1
，超过
99KW
为
1000
（
02030000
读取值被除以 1000）
Actual power ratio, 1.2 times rated power within 99KW is 1, over 99KW is 1000
(02030000 reading value is divided by 1000)
04808085
2
设置的第 1 路 DO 对应的报警状态，使用第一组报警阈值进行报警，报警信
号源于 DO1 报警源选择，DI 做报警源时双路输入时均可读到，报警状态见
注
2
Set the corresponding alarm status of DO1, The first set of alarm thresholds is
used to alarm. The alarm signal originates from the DO1 alarm selection. When
DI is used as the alarm source, it can be read by the double input channels. The
alarm status is shown in Note 2
.
04808086
2
设置的第
2
路
DO
对应的报警状态，使用第二组报警阈值进行报警，报警信
号源于 DO2 报警源选择，DI 做报警源时双路输入时均可读到，报警状态见
注 2
Set the corresponding alarm status of DO2. The second set of alarm thresholds is
used to alarm using. The alarm signal is sourced from the DO2 alarm source
selection. When DI is used as the alarm source, it can be read by the double input
channels. The alarm status is shown in Note 2.
04808087
2
读取电压值，同
02010100
，读取的数值被除以
10
倍
Read voltage value, same as 02010100, read value is divided by 10 times
04808088
2
温度 Temperature
注
:1.AAAAAAAAAAAA
使用
15H
功能写设置
645
规约地址，要求按键输入密码进入菜单后;
Note:1.AAAAAAAAAAAA writes the 645
protocol address using the 15H function,
requiring the user to enter the password to
enter the menu;
2.
7
6
5
4
3
2
1
0
DI2
DI1
L-P
H-P
L-I
H-I
L-U
H-U
第
2
路开
关量输
入
No. 2
switch
input
第
1
路
开关量
输入
No. 1
switch
input
欠功率
Under
power
过功率
Overpower
欠流
Undercurrent
过流
Over
current
欠压
Under
voltage
过压
Over
voltage
DO1 告警状态
DO1 alarm status
3.
读取电压最大为
999V
，如果额定超过，使用
特殊指令 04808087 读取;
3.The maximum reading voltage is 999V. If the rating
exceeds, use the special command 04808087 to read;
