Acrel DJSF1352-RN User Manual

3
绝缘电阻
Insulation resistance
≥ 40M Ω
平均无障碍工作时间
Average barrier-free working
hours
≥50000h
环境
Environment
温度
Temperature
正常工作温度：
-25
℃～
+65
℃；极限工作温度：
-40
℃～
+70
℃；
贮存温度：
-40
℃～
+80
℃
Normal operating temperature: -25 °C ~ +65 °C; Limit working temperature:
-40 °C ~ +70 °C;
Storage temperature: -40℃～+80℃
湿度
Humidity
≤93%RH，不结露，不含腐蚀性气体
≤93%RH, no condensation, no corrosive gas
海拔
Altitude
≤2500m
脉冲常数：Pulse constant
:
最大功率<=
Maximum power
999.9W
10000
imp/kWh
9.999kW
1000
imp/kWh
99.99kW
100
imp/kWh
999.9kW
10
imp/kWh
9999kW
1
imp/kWh
最大功率
=
额定电压
*
电压比值
*
电流比值
*1.2
Maximum power = rated voltage * voltage ratio * current ratio * 1.2
4 安装指南 Installation guide
4.1 外形及安装尺寸
Shape and installation dimensions
4.1.2
产品安装
Product installation
采用标准的 DIN35mm 导轨式安装
The meter is designed by standard DIN35mm rail
mounted.
