Ultrasonic flaw detector А1212 MASTER
Operation Manual
6
ACOUSTIC
CONTROL
SYSTEMS
1.1.1 Intended use and area of application
The instrument is a portable general-purpose ultrasonic device.
The instrument is designed for searching, evaluation and localization of various discontinuities, defects and irregularities
in different objects made of metal and plastic.
The flaw detector allows generation, registration and recording of time realizations of pulse ultrasonic signals in its memory.
A color TFT display indicates the ultrasonic signals in form of A-Scans. The instrument provides both manual and automatic
measurement of time intervals, signal amplitudes as well as automatic determination of locations of the flaws.
1.1.2 Operating conditions
The instrument is designed to operate under the following conditions:
- temperature from - 30 to +55 ˚С;
- relative air humidity up to 95 % at + 35 ˚С upper temperature limit.
DESCRIPTION
AND OPERATION
1.1 INTENDED USE
1
Name of the parameter Value
Ultrasonic reconstruction range from 500 to 14,999 m/s
Operating frequencies of transducers from 0.5 to 15.0 MHz
Tuning range of amplification (gain) of the receiving transducer (gain regulation range) from 0 to 100 dB
Gain deviation ±1.0 dB
Measurement range of the time intervals at frequency 2.5 MHz from 0 to 1 900 µs
Limits of permissible absolute measurement errors of the time intervals, where Т
meas.
– mea
-
sured value of time interval
±(0.1+0.0001·Т
meas.
)
Table 1
1.2 TECHNICAL SPECIFICATIONS
1.2.1 Main parameters of the device
The main technical specifications of the instrument are presented in the Table 1.
▼
