SPECIFICATIONS
10. Specications
Measuring medium:
Measuring principle:
Lowest span:
Highest span:
Overpressure protection:
Static pressure:
Pressure connections:
Enclosure:
Electrical connections:
Supply voltage:
Current consumption:
Output:
Alarm output:
Display:
Mode:
Controlling algorithm:
Setpoints:
Protection class:
Ambient temperature:
Storage temperature:
Weight:
Mounting:
Interference / emission:
Inuences / limits:
Air or inert gases
Silicon diaphragm with spring and differential transformer
0...50 Pa
0...4000 Pa
0.2 bar
max. 0.2 bar
tubing 5 mm ø or 6 mm ø
UL 94 HB; Case polyamid, cover ABS
cable inlet M16x1.5, screw terminal
Electronic protection against reversed polarization
10...30 Vdc; 24 Vac (±15%)
approx. 10 mA @ 10 Vdc, ca. 12 mA @ 24 Vdc
0...10 V (I
max
= 0.5 mA @ 10 Vdc, I
max
= 2 mA @ 20 Vdc)
Open Collector, max. 30 V / 30 mA
LCD-Display, 2 x16 characters
Measuring mode or controlling mode
PI
2 setpoints adjustable within software,
Setpoints are selectable with oating contact input
IP 54 according EN 60529
-10...50 °C
-25...60 °C
approx. 250 g
vertical, position dependence by turning of 90°: approx. 25 Pa
according EN 61000-6-2, EN 61000-6-3, CE mark
Zero error: ± 0.75 %
Sum of linearity and hysteresis
(depends on measuring range): ± 0.5 % ... ± 1 %
Temperature drift, zero point: ± 0.3 % / 10 K
Temperature drift, span: ± 0.2 % / 10 K
