ACTsmart2 Operating and Installation Manual Rev. 2
Copyright © 2015 Access Control Technology Ltd.
ACTsmart Software
ACTsmart2 Controller
ACTsmart2 Units (max. 8)
RS-485 cable (1.4km max)
3m RS-232 cable
ACTsmart2 Proximity Cards and FOBs.
ACTsmart2 System Diagram
© Copyright of Access Control Technology Ltd 2015
25
