3.3 Charger Mounting Options
The charging area should be well ventilated, dry and
adequately clean before the charger is mounted.
There must be at least 5.5 inches of spacing between the
front, back, and sides of the charger and any adjacent
walls or barriers to allow for proper cooling.
CAUTION:
Do not restrict airflow to the air filter at the front of
the charger or to the vents at the back of the
charger.
Quantum chargers offer a wide variety of mounting
options such as floor mount, wall mount, or stacked
mounting.
Wall Mounting
For wall mounting, only use mounting brackets especially designed for the Quantum Charger
Series, available from your local ACT Dealer. The wall mount is also available with a pogo stick
cable management system. Follow the installation instructions included in the Wall Mounting Kit
for proper installation.
WARNING
No pressure washing near the
Outdoor/GSE Charger
WARNING
No sprinklers should be turned
on near the Outdoor/GSE Charger
