ENGLISH
SOPROCARE • User’s manual
33
TECHNICAL FEATURES
SOPROCARE
• High sensitivity CCD 1/4”.
• Resolution: (752 x 582) PAL; (768 x 494) NTSC.
• Defi nition: 470 lines.
• Sensitivity: 2 lux.
• Lighting: seven LEDs.
• Adjustment: four preset positions (Extra-oral, Intra-oral, Tooth, Macro).
• 3 positions: PERIO mode, CARIO mode and DAYLIGHT mode.
• Non-inverted image.
• Image capture through SoproTouch or footswitch (optional).
• Angle of view: 70°.
• Cable length: 2.5m.
• Handpiece dimensions: L: 200; W: 28; H: 24 mm.
• Usable part dimensions: W: 14.4 x d: 8 mm.
• Handpiece weight: 78 g.
DOCK M_USB2
• Memory one and four images.
• Power supply: 115 V˜ - 230 V˜; 60 Hz - 50 Hz
• 1 PAL or NTSC video output.
• 1 PAL or NTSC S-video output.
• 1 digital USB output 2.0.
• Controller dimensions: L: 145; W: 130; H: 35 mm.
• Controller weight: 245 g.
