Product Specification
ACM-4201
Device Micron Progressive Scan CMOS
Size 1/3 inch
Effective Pixels 1280(H) x 1024(V)
Min. scene
Illumination
Color 0.5 Lux at F1.0 (2400°K, 30 IRE)
Lens f4.2mm / F1.8
Viewing Angle 75° (Horizontal)
Synchronization Sync. System Internal
Motion Detection Yes (3 Windows)
Electronic shutter 1/5 ~ 1/15,000 sec.
Fixed Shutter (Manual)
1/30 ~ 1/1,000 sec. (60Hz)
1/25 ~ 1/1,000 sec. (50Hz)
Flickerless
1/120 sec. (60Hz)
1/100 sec. (50Hz)
BLC Yes
AGC Automatic (User defined)
White Balance
AUTO,INDOOR1,INDOOR2,OUTDOOR1,OUTDOOR2, HOLD
CURRENT,MANUAL
S/N Ratio S/N Ratio Better than 44 dB
Compression MPEG-4 SP / MJPEG Selectable
Picture Resolution
SXGA (1280 x 1024)
HD 720 (1280 x 720)
VGA (640 x 480)
QVGA(320 x 240)
QQVGA(160 x 112)
Bit Rate 28K ~3M bps
Image Frame Rate
SXGA at 8 fps
HD720 at 10 fps
VGA at 30 fps
QVGA at 30 fps
QQVGA at 30 fps
Compression 8kHz, Mono, PCM
Built-in Microphone
Sensitivity: -36±3dB(0dB=1V/Pa);
S/N Ratio: more than 58dB;
Directivity: Omni-directional
Compression 8kHz, Mono, PCM
Audio Line Output Unbalanced, 1.4Vp-p, 1Vrms, 3.5mm Phone Jack
Digital Input 1, TTL, terminal block *
Digital Output 1, TTL, terminal block *
PIR sensor Yes *
Reset Button
Factory Default
LED System Status
Ethernet Ethernet(10/100 Base-T), RJ45 Connector
Protocol
TCP, UDP, IP, HTTP, HTTPS, DHCP, PPPoE, RTP,
RTSP,FTP,SMTP,DNS,DDNS,NTP,ICMP,IGMP,ARP,UPnP
Web Browser Microsoft Internet Explorer 6.0 or above
SDK ACTi SDK-10000
Security Password Protection: Configured by the administrator
Operating Temperature
-10℃~50℃ (14℉ ~ 122℉)
Power Requirement PoE (IEEE 802.3af) with Class 3
Power Consumption DC 12V 2.88W / PoE 4.32W
Dimensions (WxHxD) 88 mm x 85 mm x 39 mm (3.46" x 3.35" x 1.54")
Weight 150g (0.33 lb) (w/o bracket)
* Available only for device versions with enhancements
