Hardware Manual
18
Step 2: Prepare the Camera
IMPORTANT: When the camera is taken out from the box, the lens is covered by a thin film. DO
NOT remove this film. It is used to protect the lens from scratches or fingerprint marks which
may happen during installation. Remove this film only after the camera is securely installed and
all connections are complete.
1. Slightly twist the cover ring counter-clockwise and pull to detach it.
2. If the cables will be routed along the ceiling or wall, remove the cable tab from the
cover ring. If the cables will pass through the ceiling or wall, skip this step.
3. Install a memory card into the memory card slot of the camera, as needed.
To Next Page
