ACTi B915 - Using the Cable Gland

www.acti.com
Hardware Manual
21
Using the Cable Gland
1. Prepare the following items:
Cable Gland
Exterior-Grade
Ethernet Cable
Waterproof Tape
NOTE: Not included in the
camera package.
NOTE: Not included in the
camera package.
2. Detach the cable gland as shown below.
3. Insert the clamping nut through the Ethernet cable.
Gland Body
Clamping Nut
Sealing Rubber and Claw
