ACTi E41 - Product Specification

www.acti.com
E41 Hardware User’s Manual
10
E41
• Device
Device Type Bullet Camera
Image Sensor Progressive Scan CMOS
Day / Night Yes
Minimum Illumination Color: 0.1 lux at F1.6 (30 IRE, 2400°K); B/W: 0 lux (IR LED on)
Color to B/W switch ISP based switch, configurable
Mechanical IR Cut Filter Yes
IR Sensitivity Range 700 - 1100 nm
IR LED IR LED x 15 (850 nm)
IR Working Distance 15 m (0 lux, 30 IRE, Max Exposure Gain)
Electronic Shutter 1/5 - 1/10,000 sec (Auto mode); 1/5 - 1/2,000 sec (Manual mode)
• Lens
Focal Length / Aperture Vari-focal, f3.3-12 mm / F1.6
Iris Fixed iris
Focus Manual Focus
Mount Type Board Mount
Horizontal Viewing Angle 69.8° ~ 19.1°
• Video
Compression H.264 HP, MJPEG
Maximum Frame Rate vs.
Resolution
30 fps at 1280 x 720 (HD 720p); 30 fps at 640 x 480 (VGA);
Multi-Streaming Simultaneous dual streams based on two configurations
Bit Rate 28 Kbps - 6 Mbps (per stream)
Bit Rate Mode Constant, Variable
Basic WDR; White Balance: automatic, hold and manual;
Brightness; Contrast; Auto gain control; Digital noise reduction; Flickerless
Privacy Mask 4 configurable regions
Text Overlay User defined text on video
On-Screen Graphics User defined image layer on video
Image Orientation Image flip and mirror
• Network
Protocol & Service
TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS,
DDNS, NTP, ICMP, ARP,IGMP, SMTP, FTP, UPnP, SNMP, Bonjour
Ethernet Port 1, Ethernet (10/100 Base-T), RJ-45 connector
Security
IP address filtering; HTTPS encryption;Password protected user levels;
IEEE 802.1X network access control
• Alarm
Alarm Trigger Video motion detection (3 regions)
Alarm Response
Notify control center; Change camera settings; Command other devices;
E-mail notification with snapshots; Upload video, snapshot to FTP server
• General
Power Source / Consumption PoE Class 2 (IEEE802.3af) / 3.74 W (IR on)
Weight 639g (1.41 lb)
Dimensions (Ø x L) 77 mm x 213 mm (3.03" x 8.39")
Bundled Accessories Bracket
Environmental Casing Weatherproof (IP66 rated)
Mount Type Wall, Ceiling, Corner, Pole
Operating Temperature -20 °C ~ 50 °c (-4 °F ~ 122 °F)
Operating Humidity 10% ~ 85% RH
Approvals CE, FCC, IP66
• Integration
Unified Solution Fully compatible with ACTi software
ISV Integration Software Development Kit (SDK) available ; ONVIF compliant
Firmware Access Browser
Microsoft Internet Explorer 6.0 or newer (full functionality);
Other browsers with VLC installed (partial functionality)
Image Enhancement
Product Specification
