Hardware Manual
32
How to Connect Audio Input /Output Device (Optional)
The camera comes with a pair of audio input and output jacks where an audio input device, such
as a microphone or an audio output device, such as a speaker can be connected. The audio
jacks are covered by a rubber protection.
WARNING: Do not remove the rubber protection if the audio jack will not be used to avoid water
or dust from entering the jack.
To connect an audio device, do the following:
1. Pull to remove the rubber protection of the jack.
2. Connect the audio input device to the MIC IN jack and connect the audio output device to the
AUDIO OUT jack.
NOTE: The microphone must have a built-in amplifier. Connecting an ordinary microphone
will dwarf sounds and will result in inaudible recording.
