ACTi E83 - Step 6: Access the Camera Live View; Step 7: Adjust the Viewing Angle and Focus; Step 8: Close the Dome Cover

www.acti.com
Hardware Manual
23
Step 6: Access the Camera Live View
See Accessing the Camera on page 30for more information on how to access the Live View of
the camera.
Step 7: Adjust the Viewing Angle and Focus
Based on the live view, adjust the viewing angle and orientation of the camera. Adjustments vary
per model, for detailed information, please refer to Focus and Viewing Angle Adjustments on
page 24.
Step 8: Close the Dome Cover
1. Align the position of the dome cover shroud to the direction of the lens.
2. Tighten the three (3) screws to attach the dome cover to the camera body.
