ACTi E92 - Gang Box Mount

www.acti.com
E92 Hardware User’s Manual
10
Gang Box Adapter Mount
This camera can also be mounted using the Gang Box Converter accessory PMAX-0803 used
for 3” and 4” indoor domes. However please note that if used in combination with this accessory,
a part of the plate of PMAX-0803 will remain visible after installation as shown in the picture
below.
First, locate the three screw holes on the accessory that can be used to attach this camera
model.
Connect cables through the hole on PMAX-0803 accessory.
