Product Specification
KCM-5211E
• Device
Device Type Box Camera
Image Sensor Progressive Scan CMOS
Sensor Size 1/3.2” (4.5 x 3.4 mm)
Horizontal Resolution 1650 TVL
Day / Night Yes
Minimum Illumination Color: 0.1 lux at F1.6 (30 IRE, 2400°K); B/W: 0 lux (IR LED on)
Color to B/W switch ISP based switch, configurable
Mechanical IR Cut Filter Yes
IR Sensitivity Range 700 - 1100 nm
IR LED IR LED x 24 (850 nm)
Electronic Shutter
1/25 - 1/2000 sec (50Hz); 1/15 - 1/2000 sec (60Hz) (manual mode)
1 - 1/2000 sec (auto mode)
• Lens
Focal Length Zoom, f4.7 - 84.6 mm / F1.6 - F2.8
Zoom Ratio 18x optical
Zoom Speed 2.63 sec (1x to 18x)
Iris DC Iris
Focus Auto Focus
Horizontal Viewing Angle 48.94° - 3.61°
• Video
Compression H.264, MPEG-4 SP, MJPEG
Maximum Frame Rate
vs. Resolution (H.264, MJPEG)
8 fps at 2032 X 1920; 15 fps at 1920 X 1080 (HD 1080p); 30 fps at 1280 x
720 (HD 720p); 30 fps at 640 x 480 (VGA)
Maximum Frame Rate
vs. Resolution (MPEG-4 SP)
5 fps at 2032 X 1920; 10 fps at 1920 X 1080 (HD 1080p); 24 fps at 1280 x
720 (HD 720p); 30 fps at 640 x 480 (VGA)
4 Cropped VGA Mode (All
Compressions)
15 fps at 640 x 480 (VGA)
Multi-Streaming
Simultaneous dual steams based on two configurations in single view mode;
Multiple streams based on single configuration in 4 cropped VGA mode

Bit Rate 28 Kbps - 6 Mbps (per stream)
Bit Rate Mode Constant, Variable
S/N Ratio More than 63.2 dB
Image Enhancement
SDR(Superior Dynamic Range); White balance: automatic, hold and manual;
Brightness; Contrast; Automatic gain control; 2D+3D Digital noise reduction;
Flickerless, Defogging
Privacy Mask 4 configurable regions
Text Overlay User defined text on video
Image Orientation Image flip and mirror
• Audio
Compression 8 kHz, Mono, PCM, 16 bit encoding
Audio-In 3.5mm Phone Jack
Audio-Out 3.5mm Phone Jack
