Step 3: Mount the Camera
1. Loosen the head screw to tilt the camera, as needed, before mounting the camera to the
wall surface.
2. Mount the camera to the surface using the three (e) bundled screws.
3. Adjust the camera tilt angle, then fasten the head screw to fix the camera angle position.
Locknut
2
3
1
