ACTi Z71 - Installation Procedures; Mount the Base on the Ceiling

www.acti.com
Hardware Manual
10
Installation Procedures
Mount the Base on the Ceiling
1. Locate the positions of the holes; paste the drill template stickers on the surface and then
drill the holes according to the positions marked by drill template.
2. Insert the plastic anchors and drill a hole to lead the cables out of the ceiling.
3. Twist the camera base from its body until the two (2) arrows are aligned.
2
1
