2. Detach the clamping nut and sealing insert from the gland body:
3. Insert the clamping nut into the Ethernet cable.
4. Insert the sealing insert through the Ethernet cable.
5. Insert the cable through the gland body.
Gland Body
Clamping Nut
Sealing Insert
