SYMBOL
PARAMETER
CONDITIONS
MIN
TYPICAL
MAX
UNITS
STEREO AUDIO INPUT (AUDIO LINE-IN)
Vin
Input peak-to-peak voltage
f = 1 kHz
Zo = 600 Ω
-
-
3.3
Vpp
Zin
Input impedance
-
-
27
-
kΩ
BW
Bandwidth
A = ±3 dB
20
-
20000
Hz
OUTPUTS
STEREO AUDIO OUTPUT (AUDIO LINE-OUT)
Vo
Output rms voltage
f = 1 kHz
Zin = 10 kΩ
-
0.5
0.7
VRMS
Zo
Output impedance
-
-
-
600
Ω
BW
Bandwidth
A = ±3 dB
20
-
20000
Hz
SNR
Signal Noise Ratio
f = 1 kHz
Zin = 10 kΩ
80
-
-
dB
THD
Total Harmonic Distortion
f = 1 kHz
Zin = 10 kΩ
-
-
0.5
%
RADIO STEREO AUDIO OUTPUT (RADIO LINE-OUT)
Vo
Output rms voltage
f = 1 kHz
Zin = 10 kΩ
-
0.5
0.7
VRMS
Zo
Output impedance
-
-
-
600
Ω
BW
Bandwidth
A = ±3 dB
300
-
15000
Hz
SNR
Signal Noise Ratio
f = 1 kHz
Zin = 10 kΩ
80
-
-
dB
THD
Total Harmonic Distortion
f = 1kHz
Zin = 10 kΩ
-
-
0.5
%
SPEAKER OUTPUTS (POWER AUDIO OUTPUT)
ZL
Speaker load
VSS = 28 V
4
-
-
Ω
Po
Output RMS power
f = 1 kHz
ZL = 4 Ω
THD = 1%
VSS = 28 V
-
15
-
W
f = 1 kHz
ZL = 4 Ω
THD = 10%
VSS = 28 V
-
20
-
W
f = 1 kHz
ZL = 4 Ω
THD = 10%
VSS = 14 V
-
10
-
W
