13. Technical Specifications
13.1. Electrical Specifications
SYMBOL
PARAMETER
CONDITIONS
MIN
TYPICAL
MAX
UNITS
POWER SUPPLY INTERFACES
POWER SUPPLY INPUT
VSS
DC supply voltage
-
11
24
30
V
ISS
DC supply load current
VSS = 24 V
-
-
10
A
VSS = 14 V
-
-
10
A
ISS
STBY
DC supply standby load
current
ACC = 0 V
-
-
45
mA
ANTENNA POWER OUTPUT
Vo
DC output voltage
Output enabled
11.8
12
12.3
V
Output disabled
-
0
-
V
Io
DC output current
Output enabled
-
-
300
mA
RELAY POWER OUTPUT
Vo
DC output voltage
VSS = 24 V
Output enabled
-
0
-
V
VSS = 24 V
Output disabled
-
Z
-
V
Io
DC output current
VSS = 24 V
Output enabled
-
-
200
mA
USB POWER OUTPUT
Vo
DC output voltage
-
-
5
-
V
Io
DC output current
-
-
-
1.2
A
INPUTS
MICROPHONE INPUT
Vin
Input peak voltage
f = 1 kHz
Zo = 600 Ω
-
5.5
-
mVp
Zin
Input impedance
-
2
-
-
kΩ
BW
Bandwidth
A = ±3 dB
200
-
4000
Hz
