Getting to Know the Extender
is chapter describes the location and uses of the Extender’s LEDs,
ports, and buttons.
Front Panel
e front panel features LEDs that illuminate green when power, available
ports, and/or wireless bands are functioning and in use.
5
Power
2.4GHz radio
5GHz radio
Ethernet port 1
Ethernet port 2
Coax port
