Actisense DST-2-C-150 - Specifications

Page 12© 2016 Active Research Limited
Specications
Parameter Conditions Min. Max. Unit
Supply
Supply voltage 10 28 V
Supply current, no load (see note 1)
Supply voltage = 12v 55 80 mA
Supply voltage = 24v 50 80 mA
Supply current, loaded (see note 1)
Supply voltage = 12v 70 130 mA
Supply voltage = 24v 65 130 mA
NMEA
Output voltage between +/- and ground
(see note 2)
Logical ‘1’/stop bit 0.0 0.5 V
4.8 5.2 V
Output current (see note 2)
At maximum load, drive voltage
reduces to 2v
- 10 mA
Output short circuit current. 50 55 mA
Baud rate - xed (see note 3) 4.8 kbit/sec
Data output rate 1 secs
Depth Sounder
Depth range, using narrow-beam sensor
(like the Airmar P66)
0-10 Knots, ideal conditions 0.3 100 metres
10-40 Knots, ideal conditions 0.3 100 metres
Depth range, using wide-beam sensor (like
the Airmar DT800)
0-10 Knots, ideal conditions 0.3 100 metres
10-40 Knots, ideal conditions 0.3 60 metres
Depth sounding frequency tolerance Around the designed frequency -2 +2 kHz
Speed / Log
Speed measurement Sensor dependant 0.5 50 Knots
Temperature
Temperature measurement, using 10kΩ @
25ºC thermistor (all Airmar models)
Sensor dependant -10 +50 ºC
General
Ambient temperature -20 +70 °C
Table 3 – DST-2 specications
All specications are taken with reference to an ambient temperature (T
A
) of +25°C.
Note:
1. The maximum quoted currents are for very short periods (less than 0.5 milliseconds) only.
2. NMEA output is RS-485 compatible.
3. NMEA 0183 inputs and outputs on the DST-2 are xed to 4800 baud. Custom Baud rates and custom data rates
are available if required for specialised installations.
