ENGLISH
20
GB
INTRODUZIONE
SYMBOL INTERPRETATION
SPECIFICATIONS
MODEL
DISPLACEMENT cm³
POWER Kw / CV
IDLER RPM
MAXIMUM RPM ALLOWED
CARBURETOR
IGNITION
FUEL TANK CAPACITY
OIL TANK CAPACITY
LUBRIFICATION OIL SYSTEM
DIMENSIONS (L X W X H mm.)
WEIGHT (only engine) KG.
BAR LENGTH
CHAIN TYPE
ACTIVE 56.56ACTIVE 51.51 ACTIVE62.62
50.86
2800 giri/min.
13.200 giri/min.
DIAPHRAGM TYPE WALBRO “PRIMER TYPE”
DIGITAL
0.65 lt.
AUTOMATIC OIL PUMP WITH FLOW SCREW ADJUSTMENT
400 X 240 X 265
MODEL
PRESSURE LEVEL POWER LEVEL VIBRATIONS LEVEL
51.51 - 56.56 - 62.62
LpA av - EN 608 - ISO 7182
LwA av - EN 608 - ISO 9207
ISO 7505 m / s²
99 dB (A)
115 dB (A)
FRONT: 3,0 m/s²
56.00
61.48
40 , 45 , e 50 cm.
0.35 LT.
5.6
.325” e 3/8”
REAR: 4,0 m/s²
Handles:
2.7 / 3.8
3.0 / 4.1
3.4 / 4.6
Read operator’s instruction book before
operating this chain saw
Wear safety head, eye and ear protection
Warning, danger and caution
Use the chain saw with both hands
Warning! Kickback it’s danger
