10 11
1. Unplug unit.
2. Remove the back
cover screw.
3. Remove back cover. Press
the sides to unlatch, then tilt
the bottom out to remove.
4. Remove two (2)
thumbscrews securing the
top of the Filter Assembly.
5. Remove the Filter Assembly
by pulling back the top, then
lifting up and out.
REMOVING THE PURIFIER PLATE & ACTIVEPURE® (RCI) CELL
REMOVING THE FILTER ASSEMBLY
WARNING: Do not operate the AP3000 without the Filter Assembly and back cover properly installed.
Use genuine activTek
replacement parts
only. Parts from
anyone other than
activTek may damage
your unit and void
your warranty.
NOTE:
4. Remove two (2)
thumbscrews.
5. Slide the
ActivePure® (RCI)
Cell down and
out of unit.
1. To remove the purification plate, grasp edge
of plate in the center and gently pull out.
2. Unlock the ActivePure® (RCI)
Cell connector by pressing on
the connector’s locking tabs.
3. Pull the connector
straight out to unplug.
NOTE: If the plate is difficult to remove,
gently press down on the lower
metal contact tab
WARNING:
Do not operate AP3000 without the Filter Assembly and back cover properly installed.
