Installation and Commissioning Guide
Split Ducted ESP Indoor Unit
Installation and Commissioning Guide - Split Ducted ESP Plus/Ultima Indoor Unit
Doc. No.0525-078 Ver. 2 190925
NOTE
Typically in manual mode the fan takes approx 30 seconds to reach set speed.
The above graph represents the approximate time taken for the fan to achieve its set speed upon selection.
In ESP mode the time will vary depending on the duct system and the number of zones open or closed at time of
selection. Typically it will take approximately 3 minutes to achieve set speed from all zones open to 1 zone open.
For further info visit www.actronair.com.au
