19. Key Parts List
ESP PLUS MODELS ESP ULTIMA MODELS
ITEM DESCRIPTION
PART
NUMBER
SRV131E
SRV151E
SRV171E
SRV191E
SRV201E
SRV231E
SRM151E
SRM171E
SRM191E
SRM201E
SRM231E
1 EC ID Fan
2520-313 --- --- --- --- --- 1 --- --- --- --- 1
2520-330 1 1 1 --- --- --- 1 1 --- --- ---
2520-334 --- --- --- 1 1 --- --- --- 1 1 ---
2 Indoor Coil Assembly
1040-154 --- --- --- --- --- 1 --- --- --- --- 1
1040-156 --- 1 --- --- --- --- 1 --- --- --- ---
1040-159 --- --- 1 --- --- --- --- 1 --- --- ---
1040-169 1 --- --- --- --- --- --- --- --- --- ---
1040-177 --- --- --- 1 1 --- --- --- 1 1 ---
3 Sensor Indoor Coil In 2060-016 1 1 1 1 1 1 1 1 1 1 1
4 Sensor Indoor Coil Out 2060-021 1 1 1 1 1 1 1 1 1 1 1
5 Coil Piston
4540-076 1 --- --- --- --- --- --- --- --- --- ---
4540-110 --- 1 --- --- --- --- 1 --- --- --- ---
4540-128 --- --- 1 1 1 1 --- 1 1 1 1
6 EXV Stator Coil 4550-031 1 1 1 1 1 1 1 1 1 1 1
7 EXV Assembly
4550-032 --- --- --- --- --- 1 --- --- --- --- 1
4550-033 1 1 --- --- --- --- 1 --- --- --- ---
4550-034 --- --- 1 1 1 --- --- 1 1 1 ---
8
ID Control Board - AMIB-P1DV 2020-113 1 1 --- 1 --- --- 1 --- 1 --- ---
ID Control Board - AMIB-3PDV 2020-114 --- --- 1 --- 1 1 --- 1 --- 1 1
9 ECM Filter 4080-013 --- --- --- 1 1 1 --- --- 1 1 1
10 Remote Zone Sensor LM-RS-2 1 1 1 1 1 1 --- --- --- --- ---
11 Duct Bead Sensor AERSS 1 1 1 1 1 1 --- --- --- --- ---
12 Zone Control LM-ZC-2 --- --- --- --- --- --- 1 1 1 1 1
13 Zone Sensor LM-ZS-2 --- --- --- --- --- --- 1 1 1 1 1
14 8 Zone Module
8Z-VAV --- --- --- --- --- --- 1 1 1 1 1
8Z-24V 1 1 1 1 1 1 --- --- --- --- ---
