5
Installation and Commissioning Guide
Split Ducted ESP Indoor Unit
Installation and Commissioning Guide - Split Ducted ESP Plus/Ultima Indoor Unit
Doc. No.0525-078 Ver. 2 190925
03. Components Overview
03.01. Indoor Unit Components Overview
EC MOTOR
INDOOR
UNIT
LID CONTROL
PANEL
ID COIL
INDOOR
CONTROL PANEL
8 ZONE
MODULE
03.02. Indoor Unit Electrical Panel Overview
* EMC Filter - not fitted to SRV131E, SRV151E and SRV171E models.
EMC FILTER *
8 ZONE
MODULE
INDOOR UNIT
CONTROL BOARD
