R410A PRESSURE  TEMPERATURE CHART
Temp
o
C
Pressure
KPa
Temp
o
C
Pressure
KPa
Temp
o
C
Pressure
KPa
Temp
o
C
Pressure
KPa
- 60 - 34.4 - 28 194.9 4 805.9 36 2090.7
- 59 - 30.7 - 27 206.9 5 834.1 37 2145.5
- 58 - 26.8 - 26 219.2 6 862.9 38 2201.3
- 57 - 22.8 - 25 231.9 7 892.6 39 2258.2
- 56 - 18.6 - 24 245.1 8 922.8 40 2316.1
- 55 - 14.2 - 23 258.7 9 953.8 41 2375.1
- 54 - 9.6 - 22 272.6 10 985.4 42 2435.1
- 53 - 4.8 - 21 286.9 11 1017.8 43 2496.2
- 52 0.8 - 20 301.7 12 1050.9 44 2558.5
- 51 5.3 - 19 316.9 13 1084.7 45 2621.8
- 50 10.7 - 18 332.6 14 1119.2 46 2686.2
- 49 16.3 - 17 348.7 15 1154.6 47 2751.8
- 48 22.2 - 16 365.2 16 1190.7 48 2818.5
- 47 28.2 - 15 382.3
17 1227.5
49 2886.4
- 46 34.0 - 14 399.7
18 1265.2
50 2955.5
- 45 40.9 - 13 417.7 19 1303.6 51 3025.7
- 44 47.8 - 12 436.2 20 1342.9 52 3097.2
- 43 54.8 - 11 455.1 21 1382.9 53 3169.9
- 42 62.1 - 10 474.6 22 1423.9 54 3243.7
- 41 69.6 - 9 494.6 23 1465.7 55 3318.9
- 40 7 7.4 - 8 515.1 24 1508.3 56 3395.2
- 39 85.5 - 7 536.2 25 1551.8 57 3472.9
- 38 93.9 - 6 557.8 26 1596.2 58 3551.8
- 37 102.5 - 5 579.9 27 1641.4 59 3631.9
- 36 111.5 - 4 602.6 28 1687.6 60 3713.5
- 35 120.8 - 3 625.9 29 1734.6 61 3796.3
- 34 130.4 - 2 649.8 30 1782.6 62 3880.5
- 33 140.3 - 1 674.3 31 1831.6 63 3965.9
- 32 150.5 0 699.4 32 1881.5 64 4052.8
- 31 161.1 1 724.9 33 1932.3 65 4140.9
- 30 171.9 2 751.3 34 1984.1 66 4230.6
- 29 183.3 3 778.3 35 2036.9 67 4321.5
