Installation and Commissioning Guide
Split Ducted Outdoor Units
34
. Key Parts List
DESCRIPTION
PART
NUMBER
CRA300T SCA260C SCA290C SCA300C SCA330C SCA340C SCA400C
Compressor
1560-436 --- 1 --- --- --- --- ---
1560-437 --- --- 1 --- --- --- ---
1560-440 2 --- --- 2 --- --- ---
1560-438 --- --- --- --- 1 --- ---
1560-463 --- --- --- --- --- 2 ---
1560-459 --- --- --- --- --- --- 2
Crankcase Heater
2025-006 --- 1 1 --- 1 --- ---
2025-005 2 --- --- 2 --- 2 2
Outdoor Fan
2505-130 --- 2 --- --- --- --- ---
2505-106 2 --- 2 2 2 2 ---
2505-134 --- --- --- --- --- --- 2
Outdoor Control Board
2020-097 --- 1 1 --- --- --- ---
2020-045 1 --- --- 1 1 1 ---
2020-100 --- --- --- --- --- --- 1
Stage 2 Control Board 2020-009 1 --- --- 1 --- 1 1
HP Switch 2060-019 2 1 1 2 1 2 2
LP Switch 2060-020 2 1 1 2 1 2 2
Metering Device - (0.0591”) Piston 4540-059 --- 2 --- --- --- --- ---
Metering Device - (0.0625”) Piston 4540-062 --- --- 2 --- --- --- ---
Metering Device - (0.0670”) Piston 4540-067 2 --- --- 2 --- --- ---
Metering Device - (0.0689”) Piston 4540-068 --- --- --- --- 2 2 ---
Metering Device - (0.0760”) Piston 4540-076 --- --- --- --- --- --- 2
