User’s Manual T1-16 Tactical Ascender
SYSTEM DESCRIPTION
SYSTEM DESCRIPTION
NO PART
1 Rope grab system
2 Primary connection
3 Sling
4 Attachment karabiner
5 Chassis
6 Schrader valve
7 Connector
NO PART
8 Housing
9 Speed handle
10 Control panel
11 Emergency descent handle
12 Secondary connection point
13 Lifting handle
