ActSafe T1-16 - Connect to Rope

20
© Copyright ActSafe Systems AB
USAGE
Connect to rope
1. Place the ascender on the ground.
2. Open the rope cover.
4. Put the rope around the rope grab.
5. Close the rope cover.
3. Form a loop on the rope and
push it through the rope guide
just above the rope grab.
6. Connect the primary connection
karabiner to the EN 813 connection
point of the full body harness and
check the karabiner is locked.
Check that the live rope exits to the left
and that the rope cover is fully closed.
Attaching the rope incorrectly can result
in serious injury or death. Always use the
ascender with a backup rope system.
Make sure that the rope is attached
correctly before use.
DANGER
Use the motor to facilitate when placing the
rope around the rope grab.
Drive the ascender to waist level to simplify
connection to harness.
RECOMMENDATION
