User’s Manual T1-16 Tactical Ascender
TECHNICAL DATA
NOTE The performance is tested with an
unused 11 mm, unwatered rope at room
temperature.
TECHNICAL DATA
PERFORMANCE/PART VALUE COMMENT
Rope
Static / Semi Static rope
10-13 mm EN1891
Safe Working Load (SWL) 150 kg
Overload limit 180 kg (approx)
Max ascent speed 0-102 m/min Continuous adjustment.
Descent speed 0-145 m/min @ 120 kg Continuous adjustment.
Emergency descent speed 0-235 m/min @ 120 kg Continuous adjustment.
Battery capacity 350 m +/-15% with 120 kg load At 20°C. Applies for a new battery.
Charging time 45 min At 20°C normal battery temperature.
Internal temperature range -20 °C to + 50°C
Over heating protection Yes
Weight 17 kg Including internal battery.
Dimentions 37 x 28 x 30 cm (L x W x H)
Water proof 10 m
Can be equipped to allow ascent
from greater depths.
Operable water depth 1.5 m
Remote control range 150 m
Remote has to be in the line of sight
with the ascender.
Speed, load, characteristics of ascent/
descent will aect the battery capacity; in
many cases the capacity may well exceed
the 400 meters on one charge.
