Install Batteries
Wireless Sensor - 4 “AA” Batteries Required (not included)
Main Unit - 3 “AA” Batteries Required (not included)
NOTE: Install all batteries in both units within a 6 minute period to ensure proper
wireless functionality. Always install batteries into the wireless sensor FIRST.
Install Batteries
NOTE: Install all batteries in both units within a 6 minute period to ensure proper
wireless functionality. Always install batteries into the wireless sensor FIRST.
GENTLY SQUEEZE OUTER
CASING AND PULL INNER
INSTRUMENT POD OUT
1
SET THE OUTER CASING
ASIDE, TAKE CARE THAT IT
IS NOT DROPPED
2
REMOVE BATTERY
COMPARTMENT COVER
REPLACE BATTERY
COMPARTMENT COVER
RE-INSTALL INNER
INSTRUMENT POD UNTIL
TABS ALIGN AND YOU
YOU HEAR A “CLICK”
3
REMOVE BATTERY
COMPARTMENT COVER
1
REPLACE BATTERY
COMPARTMENT COVER
3
INSERT 3 FRESH “AA”
BATTERIES
2
5
6
INSERT 4 FRESH “AA”
BATTERIES AND REPLACE
BATTERY COMPARTMENT
COVER.
4
REMOVE
BATTERY
DOOR
SQUEEZE
PULL
INSERT
SQUEEZE
REMOVE
BATTERY
DOOR
NOTE: A/B/C SWITCH SELECTION
MUST MATCH WIRELESS SENSOR
A/B/C SELECTION
NOTE: A/B/C SWITCH SELECTION MUST
MATCH MAIN UNIT A/B/C SELECTION
PLEASE DISPOSE OF OLD OR DEFECTIVE BATTERIES IN AN ENVIRONMENTALLY SAFE WAY
AND IN ACCORDANCE WITH YOUR LOCAL LAWS AND REGULATIONS.
BATTERY SAFETY: Clean the battery contacts and also those of the device prior to battery
installation. Remove batteries from equipment which is not to be used for an extended period of
time. Follow the polarity (+/-) diagram in the battery compartment. Promptly remove dead
batteries from the device. Dispose of used batteries properly. Only batteries of the same or
equivalent type as recommended are to be used. DO NOT incinerate used batteries. DO NOT
dispose of batteries in re, as batteries may explode or leak. DO NOT mix old and new batteries or
types of batteries (alkaline/standard). DO NOT use rechargeable batteries. DO NOT recharge
non-rechargeable batteries. DO NOT short-circuit the supply terminals.
