uuSurround View Camera System
*
u
578
You can display the ground view screen using all the four cameras for the system.
Pressing the CAMERA button when the vehicle speed is at below 12 mph (20 km/h)
changes the image as follows.
■
Checking for the Sides of Your Vehicle
1Checking for the Sides of Your Vehicle
When the vehicle speed exceeds 16 mph (25 km/h),
the front or side view on the screen automatically
switches to the audio/information screen. The front
or side view screen resumes when the vehicle speed
is reduced below 12 mph (20 km/h).
0 mph (0 km/h)
Down Up
Camera
Screen
Camera
Screen
Audio/Information
Screen
Audio/Information
Screen
16 mph (25 km/h)
12 mph (20 km/h)0 mph (0 km/h)
Front Wide View + Ground ViewAudio/Information Screen
Approximate distance
the reference line
indicates.
Press the CAMERA
button.
approx. 3 feet (1 m)
Blind spots appear
in black.
Side View + Ground View
22 ACURA MDX-31TYA6000_02.book 578 ページ ２０２０年１１月５日 木曜日 午前１１時３９分
To Next Page
