6
Quick Reference Guide
Map Screen Legend
The color of the map is different depending on the selected map color scheme.
Exploration Mode
In exploration mode, you can browse the map or select a location/POI icon directly from the map. (P53)
Select EXPLORE to use the map in the exploration mode.
Current vehicle
position
MENU
Select to change the navigation
settings. (P15 )
Map Layers
Select to change layers to overlay
on the map. (P30 )
Map scale
Find (P45)
Nearby (P52)
Compass
Select to change the map
orientation. (P31)
EXPLORE (P53 )
Zoom in/out
Select to zoom in or out of an area.
Pin Mode (P53)
POI icon (P54)
Re-center
Select to go back to the
current vehicle position.
Zoom in/out
Select to zoom in or out
of an area.
Traffic incident icon
Traffic flow indicator
Black: Blocked
Dark Red: Heavily Congested
Red: Congested
Green: Smooth
Orange: Heavy
