uuChecking and Maintaining Wiper BladesuChanging the Rear Wiper Blade Rubber
Maintenance
Changing the Rear Wiper Blade Rubber
1. Raise the wiper arm off.
2. Pivot the bottom end of the wiper blade up
until it comes off from the wiper arm.
3. Slide the blade out of the wiper.
4. Remove the retainers from wiper blade and
mount to a new rubber blade.
1Changing the Rear Wiper Blade Rubber
NOTICE
Do not try to forcefully lift up the wiper arm.
The wiper arm may be damaged if it is lifted too high.
NOTICE
Avoid dropping the wiper arm, as it may damage the
rear window.
Blade
Retainer
Rubber
