Spark Plugs
2. Disconnect the three ignition coils
from the wire harness by squeez-
ing the harness end of each con-
nector and pulling.
3. Remove the two 10 mm bolts
holding the ignition coil. Remove
the ignition coil by pulling it
straight out as you twist it slightly.
4. Remove the spark plug with
a five-eighths inch (16 mm) spark
plug socket.
5. Put the new spark plug into the
socket; then screw it into the hole.
Screw it in by hand so you do not
crossthread it.
Maintenance
10 mm
BOLT
IGNITION COIL
SPARK PLUG SOCKET
To Next Page
