DTC P0010: VTC OIL CONTROL SOLENOID VALVE MALFUNCTION
1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Start the engine. Hold the engine speed at 3,000 RPM with no load (in Park or neutral) until the radiator
fan comes on, then let it idle.
4. Do the VTC TEST in the INSPECTION MENU with the HDS.
5. Check for Temporary DTCs or DTCs in the DTCs MENU with the HDS.
Is DTC P0010 indicated?
YES: Go to step 6.
NO: Intermittent failure, system is OK at this time. Check for poor connections or loose
terminals at the VTC oil control solenoid valve and the ECM/PCM.
6. Turn the ignition switch OFF.
7. Disconnect the VTC oil control solenoid valve 2P connector.
8. Measure resistance between VTC oil control solenoid valve 2P connector terminals No. 1 and No. 2.
Is there 6.75-8.25 ohm?
YES: Go to step 9.
NO: Go to step 15 .
DTC P0340 CMP Sensor A No Signal
DTC P0341 CMP Sensor & CKP Sensor Incorrect Phase Detected
DTC P0344 CMP Sensor A Intermittent Interruption
DTC P2646 Oil Pressure Switch Circuit Low Voltage
DTC P2647 VTEC Oil Pressure Switch Circuit High Voltage
DTC P2648 VTEC Solenoid Valve Circuit Low Voltage
DTC P2649 VTEC Solenoid Valve Circuit High Voltage
2004 Acura TSX
2004 ENGINE PERFORMANCE VTEC/VTC - TSX
Wednesday, March 12, 2008 2:17:58 AM Page 2
