Fig. 13: Removing The VTEC Oil Pressure Switch & Installing The Special Tools & Installing The
VTEC Oil Pressure Switch To The Oil Pressure Gauge Adapter
11. Turn the ignition switch ON (II).
12. Do the VTEC TEST in the INSPECTION MENU with the HDS.
13. Check the oil pressure.
Is the oil pressure below 49 kPa (0.5 kgf/cm
2
, 7 psi)?
YES: Inspect the VTEC system. If it is OK, replace the VTEC solenoid valve (see VTEC
SOLENOID VALVE REMOVAL/INSTALLATION ), then go to step 21 .
NO: Go to step 14.
14. Turn the ignition switch OFF.
15. Jump the SCS line with the HDS.
16. Disconnect the VTEC oil pressure switch 2P connector.
17. Disconnect ECM/PCM connector B (24P).
18. Check for continuit
y
between ECM/PCM connector terminal B11 and bod
y
g
round.
2004 Acura TSX
2004 ENGINE PERFORMANCE VTEC/VTC - TSX
Wednesday, March 12, 2008 2:17:58 AM Page 21
