9
OPERATION
Using the Weather Station
Learning Mode
Self-Calibrating Forecasting uses a unique algorithm to analyze changes in
pressure over a time period (called Learning Mode) to determine your altitude.
After 14 days, the Learning Mode icon disappears from the display screen. At
this point, the self-calibrated pressure is tuned in to your location and the unit is
ready for superior weather prediction.
Weather Forecast
AcuRite’s patented Self-Calibrating Forecasting provides your personal forecast
of weather conditions for the next 12 to 24 hours by collecting data from the
sensor in your backyard. It generates a forecast with pinpoint accuracy -
personalized for your exact location.
Moon Phase
Track the phases of the moon, conveyed through simple lunar phase icons:
Barometric Pressure
Subtle variations in barometric pressure greatly affect the weather. This
weather station displays the current pressure with an arrow icon to indicate
the direction the pressure is trending (FALLING, STEADY, or RISING).
FULL
NEW WAXING
CRESCENT
WANING
CRESCENT
1ST
QUARTER
3RD
QUARTER
View the complete list of icons at www.AcuRite.com/acurite-icons
SNOW / RAIN
MIX LIKELY
CHANCE
OF RAIN
SNOW
LIKELY
STORMY
& WINDY
CLOUDY
(flashing=stormy)
High & Low Records
Today’s high and low records are displayed for indoor temperature and humidity
and outdoor temperature. Today’s records automatically clear at 12:00am
midnight every day. View today’s high or low records by pressing and releasing
the “▲” or “▼” buttons. Press and release again to view current readings.
To manually clear all of today’s LOW recorded values, press and release the
“▼” button to view low records, then press and hold the “▼” button for 2
seconds. Dashes display to conrm you have cleared the LOW records.
