A 2 0 0 0 - S E R I E S A M P L I F I E R U S E R G U I D E
©2012 Indy Audio Labs, LLC all rights reserved / Revision20120420
Document No. 1000571
technical specifications
All Models
Power output 200W into 8Ω, multiple channels driven
300W into 4Ω, multiple channels driven
THD < 0.03%, multiple channels driven, full power, 8 ohms
< 0.05%, multiple channels driven, full power, 4 ohms
Frequency response 20Hz to 20kHz ± 0.1dB
10Hz to 70kHz +0,-3dB
Tim/dim distortion < 0.003%
S/N >106 dB, A-weighted
Damping factor 500, 8Ω @50Hz
Input sensitivity 1W: 100mV
200W: 1.42V
Input impedance 20kΩ
Recommended loudspeaker impedance range 4-8 ohms nominal
DC offset (output) <3mV
Rail voltage +/-80Vdc
THX Ultra2 Certified
A2002 only
Number of channels driven for
continuous power spec
2 channels
Power consumption Standby: 1W
Idle: 23W
Max: 1200W
Unit dimensions (LxWxH) 13.5 x 17 x 5 (inches), 34 x 43 x 13 (cm)
Rack height 3 RU
Unit weight 29lbs (13kg)
Finish Black anodized aluminum with laser-etched markings
Shipping carton (LxWxH) 22 x 18 x 10 (inches), 56 x 46 x 25 (cm)
Carton weight 35lbs (16kg)
A2005 only
Number of channels driven for
continuous power spec
5 channels, music at 50% duty cycle
4 channels, sine wave, 8 ohms
Power consumption Standby: 1W
Idle: 75W
Max: 1440W
Unit dimensions (LxWxH) 15 x 17 x 9 (inches), 38 x 43 x 23 (cm)
Rack height 5 RU
Unit weight 47lbs (21kg)
Finish Black anodized aluminum with laser-etched markings
Shipping carton (LxWxH) 22 x 20 x 16 (inches), 56 x 51 x 41 (cm)
Carton weight 55lbs (25kg)
A2007 only
Number of channels driven for
continuous power spec
7 Channels, music at 50% duty cycle
4 Channels, sine wave, 8 ohms
Power consumption Standby: 1W
Idle: 85W
Max: 1440W
Unit dimensions (LxWxH) 15 X 17 x 9 (inches), 38 x 43 x 23 (cm)
Rack height 5 RU
Unit weight 52Lbs (24kg)
Finish Black anodized aluminum with laser-etched markings
Shipping carton (LxWxH) 22 X 20 x 16 (inches), 56 x 51 x 41 (cm)
Carton weight 60Lbs (27kg)
