ENConneCtion Diagrams anD aCCessories
660Y1400 - A
Required optional material
Applicable to Description Code
All HM TC models
Room Unit RSC
Delivered with outdoor sensor
10800034
All HM TC models
ZMC-2 Module (kit)
Manages the second heating circuit - alarm contact - only functions in conjunction with
the Room Unit RSC.
10800218
X2
All HM TC models
Clip-in interface RMCIEBV3
Enables communication between the MCBA and the Room Unit RSC.
10800036
All HM TC models
2k — VF202 contact sensor
For outlet on controlled circuit
10800045
X2
All HM TC models
RAM 5109 contact thermostat
Mandatory to protect all the oor heating circuits.
10510900
All HM TC models
12k — AF120 outdoor sensor
10510100
HM 25 / 35 / 45 TC
2 circuit manifold DN 25
With connection pipes and built-in wall mounts
10800208
HM 25 / 35 / 45 TC
Low temperature kit DN 25
Is comprised of a heating pump, two isolating valves, a check valve, two thermometers and a 3-way valve
with built-in bypass.
10800295
HM 70 / 85/ 120 TC
2 circuit manifold DN 32
With built-in wall mounts.
10800298
HM 70 / 85/ 120 TC
Manifold connection kit DN 32
Includes two stainless steel hoses Ø 1"1/2 with Ø 1"1/4 reducer
10800142
HM 70 / 85/ 120 TC
Low temperature kit DN 32
Is comprised of a heating pump, two isolating valves, a check valve, two thermometers and a 3-way valve
with built-in bypass.
10800297
X2
HM 70 / 85/ 120 TC
Servomotor ARA661
Motor for 3-way valve DN 32 with the low-temperature kit.
10800199
X2
3
2
1
4
5
6
7
6
7
6
7
